Hinged Louver Doors

Single and Double Door hinged louvers allow ventilation while providing maintenance personnel with access to mechanical equipment. Our guide (below) will assist you with the proper selection for your project.

Select a Category (click to expand):

• Wall Louver Access Doors:
  Simple and Cost Effective access through Walls

  Config.	Max Size	Technical Sheet	Detail Drawing
  Description	Description	(.pdf format)	(.dwg format)
  Single Door	36" W x 48" H	2" Deep 4" Deep 6" Deep	All Depths
  Double Door	72" W x 48" H	2" Deep 4" Deep 6" Deep	All Depths

• Wall Louver HD Doors:
  Heavy Duty and/or Large Opening access through Walls

  Config.	Max Size	Technical Sheet	Detail Drawing
  Description	Description	(.pdf format)	(.dwg format)
  Single Door	48" W x 96" H	2" Deep 4" Deep 6" Deep Latch	All Depths and Latch
  Double Door	96" W x 96" H	2" Deep 4" Deep 6" Deep Latch	All Depths and Latch

• Equipment Screen HD Doors:
  Heavy Duty access into Louver Equipment Screens

  Config.	Max Size	Technical Sheet	Detail Drawing
  Description	Description	(.pdf format)	(.dwg format)
  Single Door	48" W x 96" H	2" Deep 4" Deep 6" Deep Latch	All Depths and Latch
  Double Door	96" W x 96" H	2" Deep 4" Deep 6" Deep Latch	All Depths and Latch
